Specifications

Insulator Material: Glass filled polyester, type PBT, 94 V O, UL Rated.

Contact Material: Copper Alloy

Contact Plating: Gold over .000050” Nickel, (See Contact Plating Options).

Current Rating: 3 amp at 30°C

Contact Resistance:

Insulation Resistance:

Dielectric Strength:

Compliant Section Insertion Force:
40 lbs max per contact
Compliant Section Withdrawal Force:
10 lbs min. per contact
Recommended Board Thickness:
.093”+
-
and/or Tin
Operating Temperature:
-65 C to +125C
Current Range at +20C = 3 amp
Ambient Temp. Of +70C = 2 amp
+100C = 1 amp
