Specifications

Current Rating: 0.5 Amps
Insulator Resistance: 100 Megohms min
Contact Resistance: 40m ohm max
Dielectric Withstanding: AC 500V
Operating Temperature: -40° ~± 85° C
Contact Material: Phosphor Bronze
Insulator Material: High Temperature
Thermoplastic. UL 94V-0
Finish: See Contact Plating
