1. Accommodates .062K.008 PC Board
2. Ryton or Thermx insulator
3. 1 amp current rating
4. Insulation Resistance: 5000 M min.
5. Dielectric Withstand Voltage: 250 V DC
6. Voltage Drop: 30 m volt at rated current
7. Contact Resistance: 30 m max. at rate current
8. Board Insertion Force: 16 oz max. per contact pair using
062 [1.58mm] thick steel test blade.
9. Board Withdrawal Force: 1 oz min. per contact pair using
.062 [1.58mm] thick steel test blade.
10. Operating Temperature: -54 C to +125 C
